Arcad® Staples are designed to facilitate fast and easy insertion in a variety of applications and once implanted, return to their shape memory compressed position. Compression is achieved at the arthrodesis or osteotomy site.

  • No heat activation required.
  • Fast and easy insertion.
  • Range of sizes available from 8-25mm.
  • Symmetric or asymmetric leg lengths to fit anatomy.
  • Simple intraoperative repositioning; if required.
  • Mono-cortical or bi-cortical anchorage.
Arcad-Full-Range
staples-copy
1. Bridge Width (mm) 2. Leg Length (mm) 3. Leg Length (mm) 4. Wire Dimensions (mm) Part No.
8 8 8 1.5 x 1.2 CS020808
10 9 9 1.5 x 1.2 CS010909
10 12 14 1.5 x 1.2 CS011214
10 14 16 1.5 x 1.2 CS011416
10 15 18 1.5 x 1.2 CS011518
15 12 12 1.8 x 1.3 CS031212
15 14 14 1.8 x 1.3 CS031414
18 12 12 1.8 x 1.3 CS041212
18 14 14 1.8 x 1.3 CS041414
18 14 16 1.8 x 1.3 CS041416
18 16 18 1.8 x 1.3 CS041618
18 18 18 1.8 x 1.3 CS041818
20 18 18 1.6 x 2.5 CS051818
25 20 20 1.6 x 2.5 CS062020

One-piece Compressive Construct

The Arcad® Staples were designed to help achieve compression for fusion.

Delivered at ambient temperatures, the Nitinol (NiTi) ASTM F2063 memory metal structure induces balanced inward (“pushing”) forces. By pre-loading the staple with the Arcad® Forceps, the legs are then inserted into the guided pilot holes. Once the forceps are released, the memory of the metallic alloy exerts a compressive force on the legs as represented in the image above.

  • Immediate and dynamic compression.
  • Chamfered extremity for easy introduction.
  • Low profile / atraumatic contours that are designed to preserve soft tissue .
  • Size range allows for precise fitting and anatomic compatibility.
arcad-overall

Minimal Instrumentation

  • All required instruments are neatly configured in one sterilization module.
  • Instrumentation facilitates simple insertion, repositioning, and removal.
  • The Implantation Forceps feature a unique Lock and Load design that permits convenient, reproducible deployment and rapid insertion.
scans-arcad

Sizing decision-making support – Approximative Sizes by procedure*

Forefoot ARCAD Size
1. Akin Osteotomy 08/10
2. Bunion Repair 10
3. MTP Arthrodesis 15/18
Midfoot
4. N / C Fusion
(Navicular Cuneiform)		 15/18
5. Lisfranc Arthrodesis 15/18
6. Lapidus
Opening / Closing Wedge
Osteotomy – Base Wedge		 18
15/18
7. Calcaneal / Cuboid Fusion 20/25
8. Talo / Navicular Fusion 20/25
9. Subtalar Athrodesis 20/25



*Size example to be adjusted at the surgeon’s discretion according to the patient anatomy.
foot-diagram
Arcad Sales Brochure

Arcad® Sales Brochure

Download PDF

Education

First Metatarsophalangeal Joint Arthrodesis using Arcad Nitinol Compression Staples

The demonstration is performed by Dr. Pablo Turell.

Arcad® Nitinol Compression Staples

Overview: Hallux Valgus Surgical Procedure

Prior to use of the Novastep® system, carefully read the surgical technique, the instructions for use (IFU) and all packaging label information related to the implants and instruments.

Medical devices. Implants: Class IIb-CE1639; Instruments: Class I-CE / Class IIa-CE1639.
